16.22Resettingtheradar

Toresetradarsettingstodefaultsfollowthesteps

below:

Fromintheradarapplication:

1.SelectMenu.

2.SelectRadarSet-up.

3.SelectAdvanced.

4.SelectResetAdvanced.

Aconrmationpopupmessageisdisplayed.

5.SelectYestoconrmreset.

Radarapplication

253
