26.4GPStroubleshooting

ProblemswiththeGPSandtheirpossiblecausesandsolutionsaredescribedhere.

ProblemPossiblecausesPossiblesolutions

Geographiclocationorprevailing

conditionspreventingsatellite

x.

Checkperiodicallytoseeifaxisobtainedinbetter

conditionsoranothergeographiclocation.

GPSconnectionfault.EnsurethatexternalGPSconnectionsandcablingare

correctandfaultfree.

ExternalGPSantennainpoor

position.

Forexample:

•Belowdecks.

•Closeproximitytotransmitting

equipmentsuchasVHFradio.

EnsureGPSantennahasaclearviewofthesky.

“NoFix”GPSstatusiconis

displayed.

GPSinstallationproblem.Refertotheinstallationinstructions.

Note:AGPSStatusscreenisavailablewithinthedisplay.Thisprovidessatellitesignalstrengthandotherrelevant

information.
