Raymarine E70366 - Axiom MFD Specifications

8.
1Axiomtechspec
Power
Axiom™7Axiom™9Axiom™12
Nominalsupply
voltage:
12Vdc
Operatingvoltage
range:
8Vdcto16Vdc
Fuserequirements:
•Inlinefuse=7Amp
,or
•Thermalbreaker=7Amp
P owerconsumption:
(Maximum@12Vdc)
•Chartplotter—7.34
Watts
•DV—10.02Watts
•RV—9.84Watts
•Chartplotter—8.95
Watts
•RV—11.98Watts
•Chartplotter—15.48
Watts
•RV—18.96Watts
Note:
P owerconsumptionfiguresforDVvariantsweretakenusingaCPT-100DVStransducerandRV
variantsusingaRV-100transducer.
Environmental
Axiom™7Axiom™9Axiom™12
Operatingtemperature
range:
-25°Cto+55°C
S toragetemperature
range:
-30°Cto+70°C
Humidity:
upto93%@40°C
W ateringress
protection:
IPx6andIPx7
L CDspecification
Axiom™7Axiom™9Axiom™12
Size(diagonal):
7 .0”9.0”12.1”
T ype:
TN(TwistedNematic)IPS(In-PlaneSwitching)
Colordepth:24bit
R esolution:
WVGA800x480WXGA1280x800
R atio:
5:316:10
Illumination:
1200nits/1200cd/m
2
Viewingangle:
T op60/Bottom70/Left70/Right70Top88/Bottom88/
Left88/Right88
Numberof
simultaneoustouches:
21to16
Dataconnections
Axiom™7Axiom™9Axiom™12
T ransducer:
•DVvariant=9pin
DownVision™type
connector
•RVvariant=25pin
RealVision™type
connector
25pinRealVision™typeconnector
NMEA2000:
1xDeviceNet(maleconnectorbuiltintopowercable .)
70
