Raymarine E70367 - User Manual

Questions and Answers

P
Patrick StantonAug 17, 2025
How to fix a Raymarine E70367 Monitor that won't turn on?
- J
  Jacob RitterAug 17, 2025
  If your Raymarine Monitor doesn't turn on or keeps turning off, here are some things to check: * Make sure the relevant fuses and breakers are in good condition and properly connected; replace them if needed. * Verify the power cable is correctly oriented, fully inserted into the display connector, and locked in place. * Confirm the power supply is wired correctly, referring to the installation instructions if necessary.
J
James ArnoldAug 23, 2025
What to do if Raymarine E70367 Monitor connection is slow or keeps dropping?
- H
  Heather CastroAug 23, 2025
  If your Raymarine Monitor's connection is slow or keeps dropping, it might be due to: * Wi-Fi performance degrades over distance. Move devices closer together. * Interference being caused by other Wi-Fi enabled or older Bluetooth enabled devices. Change the Wi-Fi Channel of the device you are trying to connect to and retry the connection. * Interference from devices on other vessels. Change the Wi-Fi Channel of the device you are trying to connect to and retry the connection.
S
shannon77Aug 26, 2025
How to troubleshoot a Raymarine E70367 Monitor that cannot find a network?
- D
  Donna GomezAug 26, 2025
  If your Raymarine Monitor cannot find a network, consider the following: * Ensure Wi-Fi is enabled on both Wi-Fi devices and rescan available networks. * Some devices may automatically turn off Wi-Fi when not in use to save power. Power cycle / reboot devices and rescan available networks. * Try to enable broadcasting of the device’s network using the Wi-Fi settings on the device you are trying to connect to. * Move devices closer together or, if possible remove the obstructions and then rescan available network.
W
woodkimberlyAug 31, 2025
What to do if Raymarine Monitor touchscreen is not working?
- S
  Stanley JohnsonAug 31, 2025
  If the touchscreen on your Raymarine Monitor is not working as expected: * Check if TouchLock is enabled. Swipe your finger from left to right across the Power button swipe area to de-activate the TouchLock. * Ensure you are operating the screen with bare fingers. Bare fingers must make contact with the screen for correct operation. * If there are water deposits on the screen, carefully clean and dry the screen in accordance with the instructions provided.
D
Daniel SmithSep 5, 2025
Why does my Raymarine E70367 display behave erratically?
- R
  Robin TurnerSep 5, 2025
  If your Raymarine Monitor is behaving erratically with frequent unexpected resets, system crashes, or other erratic behavior, consider the following: * Intermittent problem with power to the display: Check relevant fuses and breakers. * Software mismatch on system (upgrade required): Go to www.raymarine.com and click on support for the latest software downloads. * Corrupt data / other unknown issue: Perform a factory reset. Important: This will result in the loss of any settings and data (such as waypoints) stored on the product.
J
Julia LevySep 8, 2025
Why is the Raymarine Monitor mobile application running slowly or not at all?
- W
  wgarciaSep 8, 2025
  If the mobile application for your Raymarine Monitor is running slowly or not at all, check these things: * Raymarine app not installed: Install mobile app from relevant app store. * Raymarine app version not compatible with MFD software: Ensure mobile app and MFD software are latest available versions. * Mobile apps not enabled on MFD: Enable “Viewing only” or “Remote Control” as required in the Mobile Apps setting on your MFD.
M
Michael ThompsonSep 12, 2025
What to do if Raymarine E70367 will not start up (restart loop)?
- S
  Shelly AdamsSep 12, 2025
  In the unlikely event that the Raymarine Monitor will not start up (restart loop) due to software corruption, try downloading and installing the latest software from the Raymarine website.
L
Lydia ThomasSep 13, 2025
Why does my Raymarine Monitor show a “No Fix” GNSS status?
- M
  Mark SanchezSep 13, 2025
  The “No Fix” GNSS status icon on your Raymarine Monitor may be displayed due to: * Geographic location or prevailing conditions preventing satellite fix. Check periodically to see if a fix is obtained in better conditions or another geographic location. * GNSS (GPS) connection fault. Ensure that external GNSS connections and cabling are correct and fault free. * External GNSS (GPS) receiver in poor location. Ensure GNSS (GPS) receiver has a clear view of the sky. * GNSS (GPS) installation problem. Refer to the installation instructions.
B
Brian WilliamsNov 19, 2025
Why can't I connect my Raymarine Monitor to the network?
- B
  Brenda JohnsNov 19, 2025
  If you're having trouble connecting your Raymarine Monitor to the network, consider these potential causes and solutions: * Ensure that Wi-Fi is enabled on your devices. * Some devices may automatically turn off Wi-Fi when not in use to save power. Power cycle/reboot devices and retry the connection. * Verify that you are trying to connect to the correct Wi-Fi network. * Make sure you are using the correct passphrase. * Bulkheads, decks, and other heavy structures can degrade and even block the Wi-Fi signal. Try repositioning the devices so the structure is removed from the direct line of sight between the devices. * Interference being caused by other Wi-Fi enabled or older Bluetooth enabled devices. Try changing the Wi-Fi Channel of the device you are trying to connect to and...
L
Lisa BurnettNov 27, 2025
Why is the scrolling image not displaying on my Raymarine Monitor?
- J
  Jacob HaysNov 27, 2025
  If the scrolling image is not being displayed on your Raymarine Monitor, check the following: * Sonar disabled: Select Ping Enable from the Sonar app’s Sounder menu. * Incorrect transducer selected: Check that the correct transducer is selected in the Sonar app’s Transducer menu. * Damaged cables: Check that the transducer cable connector is fully inserted and locked in position. * Damaged or fouled transducer: Check the condition of the transducer ensuring it is not damaged and is free from debris/fouling, clean or replace as necessary. * Wrong transducer fitted: Ensure the transducer is compatible with your system. * External sonar module: SeaTalkhs ™ / RayNet network problem: Check that the unit is correctly connected to the multifunction display or Raymarine network switch...

Summary

Important Information and Safety Warnings

Product Installation and Operation Warnings

Safety warnings for installation, operation, and high voltage hazards.

Installation Procedures

Selecting an Installation Location

Guidelines for choosing an optimal installation location, including safety warnings, environmental factors, and RF interference considerations.

Mounting Options Overview

Discusses various methods available for mounting the MFD, including bracket and surface options.

Bracket (Trunnion) Mounting

Instructions for mounting the MFD using the supplied trunnion bracket on horizontal or overhead surfaces.

Axiom 7 Flush and Surface Mounting

Procedures for flush or surface mounting the Axiom 7 model after removing the trunnion adaptor.

Surface or Flush Mounting with Rear Mount Kit

Connections and Wiring

Connections: Overview and Port Identification

Connections: Power Connection and Wiring

Detailed instructions for connecting the MFD to the vessel's 12 V DC power supply, including fuse requirements.

Connections: NMEA 2000 and SeaTalkng

Connections: Transducer and Cable Setup

Troubleshooting Common Issues

Troubleshooting: General Guide

Troubleshooting: LED Diagnostics

Troubleshooting: Power Up and Reset

Steps to resolve issues when the MFD won't turn on, keeps turning off, or requires a factory reset.

Troubleshooting: GNSS (GPS) Issues

Troubleshooting: Sonar Performance

Diagnosing and resolving problems with sonar image display, readings, and transducer connections.

Troubleshooting: Wi-Fi Connectivity

Troubleshooting steps for Wi-Fi network connection, signal issues, and performance problems.

Troubleshooting: Touchscreen Issues

Technical Specifications

Technical Specs: Axiom MFD Details

Detailed technical data for Axiom MFD models, including power, environmental, LCD, and data connections.

Technical Specs: Internal Sonar

Technical Specs: Internal GNSS Receiver

Raymarine E70367 Specifications

General

Display Type	LCD
Interface	Touchscreen
Resolution	800 x 480
Waterproof Rating	IPX6
Connectivity	NMEA2000
Cartography	Navionics+, C-MAP
Operating Temperature	+55°C
Power Supply	12/24 V DC
GPS	Integrated
