Raymarine L365 - Specifications; General Information Specifications

72
6 – Specifications
General Information
Display panel FSTN high-contrast LCD
Panel dimensions 3.6" H (61 mm) x 2.4" W (91 mm)
No. of dots 240 x 64
LCD contrast Adjustable, with temperature compensation
Backlight LCD panel, on/off
Operating modes FishFinder mode (standard mode)
Zoom mode
A-Scope mode
Digital mode
Sidelooker mode
Keys Silicon rubber
Memory backup Non-volatile, no battery required
Power source 11.0 to 16.1 V DC
Power consumption backlight off - approx. 2.0 W
backlight on - approx. 4.5 W
Dimensions (w/o bracket) 5.3" H (134 mm) x 5.2" W (133 mm)
x 2.7" D (69 mm)
Weight 1.1 lbs (0.5 kg)
Waterproofing U.S.C.G., CFR 46
EMI resistance IEC 945
Specifications
