Raymarine VCM100 - Radar Scanner Connections & Grounding

3.2Radarscannerconnection
Thepoweranddatacableconnectorisattherearoftheradar
scannerunit.
Ensuringthatthearrowonthepoweranddatacableconnectoris
alignedwiththeredtriangularmarkontheradarscannerconnector,
connectthecabletothescanners’connector,andfullyhand-tighten.
DoNOTuseawrenchoranyothertool.
Note:Iftheantennaconnectorisdisconnectedafterinitial
installation,Raymarinerecommendsthatbeforereconnecting,
youlightlycoattheconnectorthreadwithRenolitAqua2Calcium
grease.
3.3Productgrounding
Importantsafetyinformationforconnectionstoground.
Beforeapplyingpowertothisproduct,ensureithasbeencorrectly
grounded,inaccordancewiththeinstructionsinthisguide.
Groundingrequirements
ThesegroundingrequirementsareapplicableforRaymarine
equipmentsuppliedwithaseparatedrainwireorscreen.
•Theproductpowercabledrainconductor(screen)mustbe
connectedtoacommongroundpoint.
•Itisrecommendedthatthecommongroundpointisabonded
ground,i.e.withthegroundpointconnectedtobatterynegative,
andsituatedascloseaspossibletothebatterynegativeterminal.
Ifabondedgroundsystemisnotpossible,anon-bondedRF
groundmaybeused.
Bondedgroundsystem(preferred)
D117 09-1
1 2 4
3
Cablesandconnections19
