Radarscannerdimensions
D10487-2
1
2
48"- 1306 mm (51.4 in), 72"- 1918 mm (75.5 in)
402 mm (15.8 in)
324 mm (12.75 in)
111 mm
(4.4 in)
150 mm
(5.9 in)
151 mm
(5.95 in)
92 mm
(3.62 in)
140 mm
(5.5 in)
92 mm
(3.62 in)
412 mm (16.2 in) 59 mm
(2.3 in) minimum
ItemDescription
1Maximumrotation
2
Centerofrotation
Radarscannermountingsurface
Suitableradarscannermountingsurfacesincludeamastplatform,
anarch,orabridgestructure.
Ifmountingtheradarscanneronasailboat,itmaybenecessary
toinstallaradarguardtopreventthesailsoranyriggingcoming
intocontactwiththeradarscannerormountingplatform.Without
aproperradarguardthemountingplatformandtheradarscanner
couldbeseverelydamaged.
Thefollowingdiagramillustratessuitablemountingsurfacesforthe
radarscanner:
D10486-1
Radarscannermountingangle
Ensuretheradarscannerrotatesparalleltothewaterline.
Theradarbeamfromtheradarscannerisapproximately25°widein
theverticaldirection,togivegoodtargetdetectionevenwhenyour
vesselpitchesandrolls.
32
HDandSuperHDDigitalOpenArrayInstallationinstructions
