Raymarine VCM100 User Manual

48”4kWHDorSuperHD72”4kWHDorSuperHD
48”12kWHDor
SuperHD
72”12kWHDor
SuperHD
Warm-uptime75seconds75seconds75seconds75seconds
Standbytotransmit
2.5seconds2.5seconds2.5seconds2.5seconds
Environmental:
Waterproofrating
IPX6IPX6IPX6IPX6
Operatingtemperaturerange-10°Cto+55°C-10°Cto+55°C-10°Cto+55°C-10°Cto+55°C
Humidity
Upto95%at35°CUpto95%at35°CUpto95%at35°CUpto95%at35°C
Maximumwindspeed85knots85knots85knots85knots
Range
Range(Nm)Expandedrange(Nm)Pulsewidth(nominal)
PRF
0.125,0.25
N/A
75ns
3kHz
0.5
N/A
100ns3kHz
0.750.125,0.25150ns3kHz
N/A
0.5250ns3kHz
1.50.75350ns2kHz
3
N/A
450ns1.5kHz
N/A
1.5600ns1.3kHz
6+3+1.0us820Hz
Technicalspecication
55
