32
Operation
Using the Door Control
SYNCHRONIZETHEDOORCONTROL
To synchronize the door control to the garage door opener, pressthe push bar until the garage door
opener activates(itmaytake up to 3 presses). Testthe door control by pressing the push bar,each
press ofthe push bar will activate the garage door opener.
Up to 2 SmartControl Panels
®
or 4 of any other Security+ 2.0
®
door controlscan be connected to the
garage door opener.
Push Bar
LIGHT
button
Screen
Motion
Sensor
Navigation
Buttons
PUSH BAR
Press the push bar to open or close the door.
NAVIGATION BUTTONS
Use the navigation buttonsto make selectionsand program features.
LIGHT BUTTON
Press the LIGHTbutton to turn the garage door opener lights on or off. When the lights are turned on
theywill stayon until the LIGHT button is pressed again,or until the garage door opener is activated.
Once the garage door opener is activated the lights will turn offafter the specified period oftime (the
factorysetting is 4-1/2 minutes). The LIGHTbutton will not control the lightswhen the door is in motion.
SCREEN
The screen will display the time and temperature until the menu button is pressed, and then it will display
the menu options. Ifthere is a problem with the garage door opener the screen will display the Diagnostic
Code. Refer to the Troubleshooting section.
The following features are accessible through the screen using the navigation buttons:
LEARN A DEVICE
Any compatible remote controls, wireless keyless entry, Wi-Fi garage door openers,or MyQ
®
accessoriescan be programmed to the garage door opener by accessing the menu and using the
navigation buttons.
LOCK
The LOCK feature is designed to prevent activation of the garage door opener from remote controls
while still allowing activation from the door control and keylessentry. This feature is useful for added
peace ofmind when the home is empty (i.e. vacation).
TIMER-TO-CLOSE (TTC)
DO NOTenable TTC ifoperating a one-piece door. TTC is to be used ONLY with sectional doors.
Factorydefault issetto off.TTC can be setto automatically close your garage door from the fullyopen
position after a specified period of time (1, 5, 10 minute intervals or a custom setting up to 99 minutes).
The garage door opener will Beep and the lights will Flash before closing the door.The screen on the
door control can display the statusofthe TTC. TTC WILL NOT work if the garage door opener is
operating by battery power or if the safetyreversing sensorsare misaligned.This feature is NOT
intended to be the primary method ofclosing the door.A keyless entry should be installed in the event
of an accidental lock out when using this feature.
NOTE: Before enabling the TTC for the first time, or if you experience a power outage, cycle the garage
door opener open and closed to allow the TTC to set.
AUTOMATIC LIGHT
Motion Sensor
Factorydefault issetto on. This feature automatically turns on the garage door opener lights when
motion is sensed. The lights will come on for the setperiod of time,then shut off. If using the garage door
opener light as a work light disable the motion sensor,otherwise the lightwill turn offautomatically ifyou
are beyond the range ofthe sensor.
Light Feature
The lights will turn on when someone enters through the open garage door and the safety reversing
sensor infrared beam isbroken.
MAINTENANCE ALERT (MAS)
This feature assiststhe homeowner in ensuring the garage door opener system stays in good working
condition. When the garage door opener needs to be serviced (approximately 4500 garage door
opener cycles) the command (yellow) and service (red) LEDs will begin to alternately flash back and
forth. The factory setting for the MAS feature is offand can be activated at time of installation. Contact your
installing dealer for service.
