Raypak 013464F - MODELS 185 B, 265 B, 335 B & 405 B, Lo NOx ONLY: PREPARE NEW REPLACEMENT CONTROL PCB FOR INSTALLATION

P/N 241417Rev 4
Effective: 12-04-12
Replaces: 10-07-11
Page 5
MODELS 185B, 265B, 335B & 405B, Lo NOx ONLY:
PREPARE NEW REPLACEMENT CONTROL PCB FOR INSTALLATION
1. DO NOT break tab See Fig. 10 and Fig. 11.
2. No additional wiring or connections are necessary for Lo NOx operation.
DO NOT
break
tab.
DO NOT
break tab.
After control PCB is
installed, remove and
discard flag label.
Fig. 10
Fig. 11
