Raypak 2002C User Manual

48
Item Display Range When is it Displayed Description
OUTDOOR
---, -76 to 149ºF
MASTER
PIM Identity is H
TARGET = RSET
O
utdoor air temperature, the number field displays “----” if OUT-
DOOR sensor has a fault.
TARGET
---, -22 to 266ºF
MASTER
MODBUS RATE
EMS RATE
C
urrent target water temperature, the number field displays “----”
w
hen there is no current target.
POOL
“----”, -22 to 266ºF
PIM Identity is P
Current pool temperature, the number field displays “----” if the pool
s
ensor fails.
TANK
----, -22 to 266ºF
PIM Identity is WH
C
urrent system supply temperature, the number field displays “----” if
T
ank sensor fails.
SUPPLY
---, -22 to 266ºF
MASTER
C
urrent system supply temperature, the number field displays “----” if
the SUPPLY
IND SUPPLY
---, -22 to 266ºF
PIM Identity is H MODE = 3
Current temperature being supplied to the indirect, the number field
displays “----” if the indirect DHW sensor fails.
Boil OUTLET
---, -22 to 266ºF
Always
Current boiler outlet temperature as communicated from the PIM,
the number field displays “----”
Boil INLET
---, -22 to 266ºF
Always
Current boiler outlet temperature as communicated from the PIM,
the number field displays “----” if the outlet sensor fails.
Boil ∆T
0 to 252ºF
Always
Current boiler inlet temperature as communicated from the PIM, the
number field displays “----” if the inlet and/or outlet sensor fails.
DHW Supply
---, -22 to 266ºF
MASTER
PIM Identity is H
MODE = 2 OR 3
DHW SENSOR = ON
Current Indirect DHW Supply temperature, the number field displays
“----” if the DHW sensor has a fault.
Boiler 1
IDLE, POST, PREP,
STG 1, 2, 3, 4
MASTER
Shows the operation status of master boiler.
Boiler 2, 3, 4
IDLE, POST, PREP,
STG 1, 2, 3, 4
MASTER
Shows the operation status of all boilers in cascade.
View Menu
The “View” icon is turned on. BOILER and 1 segment are turned on if BOILER 2, 3 or 4 are set to ON.
Table O: View Menu
