50
Table Q: Boiler Menu
I
tem
A
pplication
D
escription
BOILER 1 ALL Enables Boiler for operation.
BOILER 2 CASCADE Enables Boiler for cascade operation.
BOILER 3 CASCADE Enables Boiler for cascade operation.
BOILER 4 CASCADE Enables Boiler for cascade operation.
IGNITION
(IGNITION 1/2, models
1532-2342)
ALL
IDLE=no CFH; PREP=pre-purge or inter-purge
between trials for ignition; IGN=trial for ignition;
BURN=burner operating; POST=post purge;
HARD=a hard lockout fault has occured requir-
ing manual high limit); and SOFT=a soft
lockout fault has occurred which interrupts the
manual high limit).
The CFH will resume after the soft lockout fault
has been corrected and a 15 min. waiting peri-
od has expired.
VENT WALL Not Available Not Available.
LIMIT TEMP ALL Current Outlet -Limit temperature.
EMS VDC ALL Current EMS signal in Volts DC.
FIRE RATE ALL PIM firing rate.
OUTLET MAX H Mode 1,2,3
Defines Max Outlet temperature offset above
Target Setpoint (Press and hold up and down
arrows for 3 seconds to enable adjustment),
see VERSA IC manual, catalog 5000.72.
OPERATOR ALL Operator Potentiometer setting on PIM.
DIFF ALL Current auto differential – Fixed by PIM.
PUMP POST ALL Sets the length of the boiler pump purge.
FLAME CUR ALL Flame current in micro-amps (µA).
MASS ALL
Thermal mass recovery, see VERSA IC manu-
al, catalog 5000.72.
IDENTITY ALL
Identifies the unit as boiler, water heater or
pool heater.
IGN TYPE ALL PIM Board type.
ID CARD ALL Identifies Raypak Identity Card.
SW ID ALL PIM Software identification number.
ERROR CODE ALL Current Error Code.
* Fixed values based on ID card
Boiler Menu
The Boiler View displays various items regarding ignition, temperature monitoring, and modulation rates. As well
a
s software and hardware information.
