59
CALL
OUT DESCRIPTION 207A 267A 337A 407A
J CONTROL BOX
1-J Transformer 120/240/24V 006736F 006736F 006736F 006736F
2-J Rocker Switch 009493F 009493F 009493F 009493F
3-J Relay Low Nox 008784F 008784F 008784F 008784F
M MISCELLANEOUS COMPONENTS
1-M Pressure Switch 1.75 PSI 006737F 006737F 006737F 006737F
Pressure Switch 11 PSI Special-See Water Pressure Switch Adj. 009133F 009133F 009133F 009133F
2-M Roll-Out Switch 300ºF 006035F 006035F 006035F 006035F
3-M PRV 125 PSI (Optional) 008091F 007224F 007224F 007224F
4-M Deliming Kit 052871F 052871F 052871F 052871F
5-M Wire/Harness 010347F 010347F 010347F 010347F
6-M Control Bezel (Includes Switch Decal)
Units manufactured prior to 1/2011 009491F 009491F 009491F 009491F
Units manufactured from 1/2011 013491F 013491F 013491F 013491F
7-M Switch/Decal-Membrane
Units manufactured prior to 1/2011 009492F 009492F 009492F 009492F
Units manufactured from 1/2011 013492F 013492F 013492F 013492F
8-M Control Bezel Cover 009487F 009487F 009487F 009487F
9-M Gasket Insulation (Swaybrace & Jacket Top) 010350F 010350F 010350F 010350F
10-M Blower / Air Pressure Switch Sample Tube 010348F 010348F 010348F 010348F
11-M To uc h-up Paint (Green) 750125 750125 750125 750125
Tou ch-up Paint (Dark Gray) 750126 750126 750126 750126
12-M Tie Down Bracket (Optional) 011636 011636 011636 011636
13-M Roll-Out Switch 250ºF (Optional) 011745F 011745F 011745F 011745F
Roll-Out Switch 250ºF (Upgrade) 011733F 011733F 011733F 011733F
14-M Texas Code Add/On (ASME Only) 012011 012011 012011 012011
P PILOT
1-P Pilot Nat. IID Lo NOx 010232F 010232F 010232F 010232F
2-P Pilot Electrode N/A N/A N/A N/A
3-P Pilot Mounting Bracket 010233F 010234F 010235F 010236F
4-P Pilot Tube 011926F 011926F 011926F 011926F
5-P Hi Tension Wire IID 010349F 010349F 010349F 010349F
6-P Adapter Nut (Metric) 011927F 011927F 011927F 011927F
R REFRACTORY
1-R Refractory Common (Left & Right) 010079F 010079F 010079F 010079F
2-R Refractory Uncommon (Front and Rear) 010080F 010081F 010082F 010083F
3-R Refractory Retainer Kit 010262F 010263F 010264F 010265F
S SHEETMETAL
1-S Jacket Top (Louvered) 010047F 010048F 010049F 010050F
2-S Flue Collector (Units with Polymer Header) 010063F 010064F 010065F 010066F
Flue Collector (Units with Metal Header) 010067F 010068F 010069F 010070F
3-S Door Assy.
Raypak 010267F 010268F 010269F 010270F
Rheem 010271F 010272F 010273F 010274F
4-S Access Panel Set (3 Pcs. Units with Polymer Header) 010311F 010311F 010311F 010311F
Access Panel Set (3 Pcs. Units with Metal Header) 010312F 010312F 010312F 010312F
5-S Jacket Side Panel Right 010313F 010313F 010313F 010313F
6-S Jacket Side Panel Left 010314F 010314F 010314F 010314F
7-S Jacket Rear Panel (2 Pcs.) 010315F 010316F 010317F 010318F
8-S Poolstat Cover/Lock 009505 009505 009505 009505
9-S High Limit Cover 010319F 010319F 010319F 010319F
10-S Base Heat Shield 010320F 010320F 010320F 010320F
11-S Up Front Control Panel 010321F 010322F 010323F 010324F
12-S High Limit Shield 010342F 010342F 010342F 010342F
13-S Weather Shield 010325F 010326F 010327F 010328F
V VENTING
1-V Indoor Stack Kit (Includes inner adapter panel) 009838 009839 009840 009841
Outdoor Stack Kit (Includes inner adapter panel) 009834 009835 009836 009837
2-V Stack Adapter 010330F 010331F 010332F 010333F
4-V Outer Stack Adapter 011461F 011462F 011463F 011464F
3-V "Pagoda" Top 010334 010335 010336 010337
LO NOx HEATERS
