Raypak 240692 - SYSTEM START-UP CONFIGURATION GUIDE; FRONT PANEL POTENTIOMETER SETTINGS; INTERIOR JUMPER & SWITCH SETTINGS SUMMARY

SYSTEM START-UP SETTINGS
SYSTEM SETTING ENTERED ON DATE:
Front panel control potentiometers (knobs)
Reset Ratio: ______ Control Band: ______
Default Value: 1:1 Default Value: 3°F
Pump off Delay: ______ Outdoor Cutoff Deadband: ______
Default Value: 3 min. Default Value: 3°F
Boiler on Delay: ______ Outdoor Cutoff Temp.: ______
Default Value: 30 sec. Default Value: 65°F
Stage on Delay: ______ Max Water Temp.: ______
Default Value: 10 sec. Default Value: 180°F
Set Point: ______
Default Value: 140°F
Optional Alternate Set Point ______
INTERIOR JUMPER & SWITCH SETTINGS:
Last Stage (J2) Output ON Switch (S2)
Mode Selector Switch (S3) Lead-Lag Switch (S4)
Bypass Switch (S5)
28
