DIMENSIONS AND TECHNICAL DATA
53
Indoor Models 992 - 1922
Indoor Models 2214 - 4224
Model
992
1182
1292
1412
1722
1922
Natural Gas
Input (MJ/h)
999
1186
1289
1412
1722
1922
Output (kW)
225
265
285
315
380
430
Propane Gas
Input (MJ/h)
933
1090
1186
1296
1581
1772
Output (kW)
205
240
265
290
350
395
Electrical Rating
240 V 50 Hz
Power (W)
100
100
100
100
100
100
Current (A)
0.42
0.42
0.42
0.42
0.42
0.42
Weight empty
Kg
310
330
360
390
440
460
Flue Connection
mm
355
405
405
455
455
505
Dimensions A
mm
1810
1915
1915
1990
2060
2130
B
mm
1330
1510
1615
1740
2070
2270
G
mm
860
860
860
860
930
930
Model
2214
2634
3164
3694
4224
Natural Gas
Input (MJ/h)
2215
2636
3165
3692
4224
Output (kW)
505
600
720
840
960
Propane Gas
Input (MJ/h)
2150
2530
3035
3540
4045
Output (kW)
480
560
675
790
900
Electrical Rating
240 V 50 Hz
Power (W)
100
100
100
100
100
Current (A)
0.42
0.42
0.42
0.42
0.42
Weight empty
Kg
625
700
780
860
940
Flue Connection
mm
610
660
710
760
815
Dimensions A
mm
-
-
-
-
-
B
mm
1550
1780
2060
2350
2640
G
mm
-
-
-
-
-
