Raypak E3T Series User Manual

6
Models
Properties ELS 0005 ELS 0011 ELS 0018 ELS 0027
Elements 1 2 2 3
 240 V 240 V 240 V 240 V
Frequency (HZ) 60 60 60 60
Power (kW) 5.5 11 18 27
Each Element Supply (kW) 5.5 5.5 (Qty 2) 9 (Qty 2) 9 (Qty 3)
Required Breaker

30/30 60/60 40/50 (Qty 2) 40/50 (Qty 3)
 100 150 150 200
Table B. 
Models
Properties ELS 0005 ELS 0011 ELS 0018 ELS 0027
 #10 #6 #8 #8
Wire Set 1 1 2 3
 30 60  40/50
Breaker Type Double Pole Double Pole Double Pole Double Pole
Breaker Quantity 1 1 2 3
Table C. 
10. OPERATION
Once the heater is installed, it can be used year round.
The user MUST makes sure the pump is not disengaged
to allow it to run until the desired temperature setting is
reached.

through it [15 gpm (57 lpm) minimum]. On the digital


ELS 0005
GRND
L1 L1
30
30
DOUBLE
POLE
BREAKER
ELS 0011
GRND
L1 L1
60
60
DOUBLE
POLE
BREAKER
ELS 0018
GRND
L2 L2
40
40
DOUBLE
POLE
BREAKER
L1 L1
4040
DOUBLE
POLE
BREAKER
ELS 0027
GRND
L3 L3
4040
DOUBLE
POLE
BREAKER
L2 L2
4040
DOUBLE
POLE
BREAKER
L1 L1
4040
DOUBLE
POLE
BREAKER
Models ELS 0005 and 0011 display the inlet temperatures
on the GPM screen by turning the knob to the right. The
outlet temperature is displayed by turning the knob to the
left.
Models ELS 0018 and 0027 have the outlet and inlet
temperatures displayed at all times.
The unit also has a one (1) minute built-in TIME DELAY to
protect it from air in the lines and to avoid burning out the


 Wire Connection to Circuit Breakers

Raypak E3T Series Specifications
