3
ASSEMBLY AND SET-UP
1 Slide the seat back frame tubes (left and right) on
to the seat bottom frame tubes (left and right) until they
hit the spring-loaded buttons on the seat bottom frame
tubes. Press both spring-loaded buttons (left and right)
on the seat bottom frame tubes simultaneously to slide
down and install the seat back frame tubes onto the
seat bottom frame simultaneously.
2 The spring-loaded buttons will pop out when
properly installed.
Attaching the Seat
WARNING: Failure to
properly engage the spring-loaded
buttons may cause the seat to
dislodge while riding and may cause
you to lose control. When correctly
engaged the seat will not rotate nor
will it move sideways. Note that
when properly engaged, the spring-
loaded buttons are clearly visible in
the holes on the seat frame.
1 Using two (2) 5 mm Allen wrenches, remove the four
(4) bolts on the front half of the frame.
2 Install the front half of the frame to the rear half of
the frame, making sure that all holes align.
3 Using two (2) 5 mm Allen wrenches, install the four
(4) bolts through the frame.
Attaching the Frame
Required Tools: Two (2) 5 mm Allen Wrenches (included)
WARNING: Failing to
properly tighten the bolts on the
frame can cause you to lose control.
To Next Page
