3
BEFORE YOU BEGIN
Remove contents from box. Remove the separators that protect the components from damage during shipping.
Inspect the contents of the box for scratches in the paint, dents that may have occurred during shipping. Because your
scooter was partially assembled and packed at the factory, there should not be any problems, even if the box
has a few scars or dents.
MAKE SURE POWER SWITCH IS TURNED “OFF” BEFORE CONDUCTING ANY ASSEMBLY OR
MAINTENANCE PROCEDURES.
Estimated Assembly and Set-Up Time
Allow up to 10 minutes for assembly, not including initial charge time.
Allow up to 4 hours for charge (see page 5 for charging information).
Charger
Note: Charger design may
vary from one shown
3.
Throttle
Head Light
Brake Lever
ON/OFF/Light Button
2.
Battery Cover
Charger Port
Motor
Required Tool
5 mm Allen Wrench
(Included)
WARNING:
DO NOT USE NON-RAZOR
PRODUCTS WITH YOUR SCOOTER.
Razor scooters have been built to
certain Razor design specifications.
The original equipment supplied at
the time of sale was selected on
the basis of its compatibility with
the frame, fork and all other parts.
Certain aftermarket products may
not be compatible and will void
the warranty.
Product ID Locations:
(See locations to the left)
1. Handlebar Stem
2. Underneath Product
3. Charger
4. UPC Side of Box (Not Shown)
Box Contents:
• E-XR
• Charger
• Owner’s Manual
• 5 mm Allen Wrench
Note: Electric scooter must
be moving at least 3 mph (5
km/h) while applying throttle to
engage motor.
1.
Collar Clamp
Taillight/Brake Light
Fork
To Next Page
