Required Tool
5 mm
Allen Wrench
Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
3
BEFORE YOU BEGIN
WARNING: DO NOT USE
NON-RAZOR PRODUCTS WITH
YOUR SCOOTER.
Razor scooters have been built to
certain Razor design specifications.
The original equipment supplied
at the time of sale was selected
on the basis of its compatibility
with the frame, fork and all
other parts. Certain aftermarket
products may not be compatible
and will void the warranty.
Remove contents from box. Remove the separators that protect the components from damage during shipping.
Inspect the contents of the box for scratches in the paint, dents that may have occurred during shipping. Because
your scooter was assembled and packed at the factory, there should not be any problems, even if the box has a few
scars or dents.
MAKE SURE POWER SWITCH IS TURNED “OFF” BEFORE CONDUCTING ANY ASSEMBLY OR
MAINTENANCE PROCEDURES.
Estimated Assembly and Set-Up Time
Allow up to 5 minutes for assembly, not including initial charge time.
Allow up to 10 hours for charge (see page 6 for charging information).
Product ID Locations:
(See locations to the left)
1. Underneath Product
2. Charger
3. UPC Side of Box (Not Shown)
Box Contents:
• Power A
5
• Charger
• Owner’s Manual
• Allen Wrench
Note: Electric scooter must be
moving at least 3 mph (5 km/h)
while applying throttle to
engage motor.
Throttle
Quick-Release Lever
Collar Clamp
Anti-Rattle Folding Mechanism
Hub Motor
Charger Port
Power Cut-off
Rear-Fender
Brake
Kickstand
ON/OFF Button
1.
2.
Charger
(Note: Charger design may
vary from one shown)
