6
CHARGING THE BATTERY
PRE-RIDE CHECKLIST
WARNING: Use ONLY
with the recommended charger.
Batteries are only to be charged
under adult supervision. The
charger is not a toy. Always
disconnect the charger before
wiping down and/or cleaning the
Power A
5
with a zdamp cloth.
The charger supplied with the
Power A
5
should be regularly
examined for damage to the cord,
plug, enclosure and other parts.
In the event of such damage, the
Power A
5
must not be charged until
it has been repaired or replaced.
Chargers have built-in overcharge
protection to prevent battery from
being overcharged.
Wall outlet - Green (stand by)
Wall outlet and product -
Red (charging)
Wall outlet and product -
Green (charged)
Note: Continue charging product
even if light turns green prior to
8 hours.
WARNING: Battery charge
can deplete over time. Periodically
recharge battery when not in use.
Your Power A
5
may not have a fully charged battery; therefore you must charge the battery prior to use. Be sure to
charge the battery in a clean, dry location away from direct sunlight, flames or sparks.
• Initial charge time: 10 hours.
• Recharge time: up to 8 hours, even if the light turns
green. Recommended maximum charging time is 24
hours.
• Always charge the battery immediately after riding.
• Fully charge battery before storing for extended
periods of time.
• Unplug charger from the wall outlet when not in use.
• Failure to recharge battery periodically may result in a
battery that will not accept a charge.
• Make sure the power button is turned OFF when
product is not in use. If the power button is left on for
an extended period of time, the battery may reach a
stage at which it will no longer hold a charge.
• Run time: Up to 40 minutes of continuous ride time.
Run time may vary depending on riding conditions,
rider weight, climate, and/or proper maintenance.
• Constant starting and stopping may shorten ride time.
• Battery life can vary depending on proper
maintenance and usage of the product.
• Do not charge at or below 32°F (0°C).
2 Note: Make sure power button
is in the OFF position. Plug the
charger into the charger port.
The light on the charger should
turn red during charging. The
light will turn green again when
charging is complete.
1 Plug the charger plug into wall
outlet. The light on the charger
should be green.
Note: If green light (LED) does not
turn on, try a different outlet.
Charger
(Note: Charger design may vary
from one shown)
LED Light
Model Voltage
(Nominal) Vdc
Capacity
(Nominal) Ah
Charge
Temperature Range
Operating
Temperature Range
Power A
5
21.6 2.75
0° to 45°C
32° to 113°F
-20° to 65°C
-4° to 149°F
Brake
Check the brake for proper function. When you step on the
rear-fender brake, the brake should provide positive braking
action. When you apply the brake with the throttle on/
engaged, the brake cut-off switch should cut power to
the motor.
Wheels
Periodically inspect the wheels for excessive wear.
Frame, Fork and Handlebars
Check for cracks or broken connections. Although broken
frames are rare, it is possible for an aggressive rider to run into
a curb or object and wreck, bend or break a frame. Get in the
habit of inspecting your scooter on a regular basis.
Hardware/Loose Parts
Before every ride, check all parts, such as nuts, bolts,
fasteners, etc., to ensure they are secure and assembled
correctly. There should not be any unusual rattles or sounds
from loose parts or broken components. If the product is
damaged, do not ride. Reference “Safety Warnings” on
pages 1 and 2 of this manual.
Safety Gear
Always wear proper protective equipment, such as an approved
safety helmet (with chin strap securely buckled), elbow pads,
and kneepads. A helmet may be legally required by local law
or regulation in your area. A long-sleeved shirt and long pants
are recommended. Always wear shoes and keep shoelaces
tied and out of the way of the wheels and motor. NEVER RIDE
BAREFOOTED OR IN SANDALS.
Laws and Regulations
Always check and obey any local laws or regulations.
Insurance
Do not assume that your existing insurance policies necessarily
provide coverage for product use. Check with your insurance
company for information regarding insurance.
