5
ASSEMBLY AND SET-UP
Attaching the Handlebars
Tool Required: 5 mm Allen Wrench
1 Using the 5 mm Allen wrench
loosen the handlebar clamp.
2 Insert the handlebar with the
throttle facing the rider.
3 Using the 5 mm Allen wrench
tighten the handlebar clamp.
4 To adjust the height of the handlebars, open the
quick-release lever and slide the T-bar to the desired
position and resecure the quick-release lever to lock
into place.
5 The tension of the quick-release lever can be
adjusted by manually tightening or loosening the Allen
bolt. Be careful not to overtighten. You should always
be able to open and close the quick-release lever by
hand and the T-bar should slide freely when the quick-
release is open.
WARNING: Failure to
properly secure the quick-release
lever may cause the T-bar to
telescope up or down while riding
and may cause you to lose control
and fall.
