44
ASSEMBLY AND SET-UP
Attaching the Seat
Required Tool: 10 mm Wrench (included)
Attaching the Handlebars
Required Tool: 6 mm Allen wrench (included)
1 Put the seat on the frame. Note: The four (4) threaded
columns at the bottom of the seat need to align with the
screw holes in the frame.
2 Tighten the four (4) lock nuts with an
10 mm wrench to secure the seat to the frame.
Inflating the Tires
The tires are inflated when shipped, but they invariably may lose some pressure between the point of manufacturing
and your purchase. Always inflate tires to the correct PSI before first time use.
Lower air pressure can result in a shorter ride time.
Periodically check tires. Reinflate when needed.
1 Remove the valve cap and using a bicycle style tire pump equipped for a Schrader-type valve, inflate the tires to
the correct PSI indicated on the sidewall of the tires. Replace the valve cap.
WARNING: Do not use the
electric scooter for the first time
until you have inflated the tires to
the correct PSI. Failure to do so may
damage your electric scooter and
void your warranty.
WARNING: Do not
overinflate, as this could damage
the tires or wheels.
Note: The pressure air supplies
found at gasoline stations are
designed to inflate high-volume
automobile tires. If you decide to
use such an air supply to inflate your
electric scooter tires, first make sure
the pressure gauge is working, then
use very short bursts to inflate to
the correct PSI. If you inadvertently
overinflate the tires, release the
excess pressure immediately.
1 Place the handlebars in the handlebar clamps. Align parallel to the fork and
tighten the bolts using a 6 mm Allen wrench. When properly tightened, the
handlebars should not move forward or backward.
