Razor rambler 16 User Manual

88
HEADLINEREPAIR AND MAINTENANCE
Replacing the Battery
Required Tools: Phillips Screwdriver (not included) and 4 mm Allen Wrench (included)
2 Using a Phillips screwdriver
remove the two (2) screws at the
front of the battery box.
5 Unplug the power
cord connector.
8 Remove the battery bracket
(lower) and battery.
3 Using a Phillips screwdriver
remove the seven (7) screws from
the side of the battery box.
6 Using a 4 mm Allen wrench,
remove the two (2) screws from the
top of the battery bracket (upper).
9 Replace with new battery.
1 Using a Phillips screwdriver
remove the two (2) screws at the
back of the battery box.
4 Remove the battery box
7 Using a 4 mm Allen wrench,
remove the two (2) screws from the
sides where the battery is attached
to the battery bracket (lower).
10 Put the battery bracket (lower)
and battery back onto the frame.
11 Using a 4 mm Allen wrench,
replace the two (2) screws at the
sides where the battery is attached
to the battery bracket (lower).
12 Using a 4 mm Allen wrench,
replace the two (2) screws at the
top of the battery bracket (upper).

Razor rambler 16 Specifications

General

Max Speed	15.5 mph
Frame	Steel
Fork	Steel
Downtube	Steel
Brake Type	Disc
Frame Material	Steel
Tires	16-inch pneumatic
Grips	Rubber
Handlebars	Adjustable height
Wheels	16-inch
Brakes	Hand-operated, rear disc brake
Kickstand	Retractable
