Razor RSF350 User Manual

9
REPAIR AND MAINTENANCE
2 Locate the fuse box attached to
the batteries. Open cover to expose
the fuse.
3 Remove the fuse and replace
with a new one of equal amperage.
Close the cover and reattach the
battery cover.
Front Wheel Replacement
Required Tools: 14 mm Wrench, 17 mm Wrench (not included)
Replacing the Fuse
Required Tool: 14 mm Wrench, 17 mm Wrench (not included)
30 Amp
Note: The arrangement of the
hardware sequence:
9-4 Locknut
9-3 Washer
Front Fork
9-2 Spacer
Wheel
9-2 Spacer
Front Fork
9-3 Washer
9-1 Axle Bolt
WARNING: Failing to
properly adjust and tighten the
nuts and bolts that affix the front
wheel can cause you to lose control
and fall.
WARNING: To prevent
shock, please follow the instructions
accordingly and do not skip or
combine any steps.
WARNING: To avoid a pinch
or injury, keep fingers away from
moving sprockets and chain.
1 Using 14 mm and 17 mm wrench loosen the locknut; slide axle bolt out
and remove front wheel.
1 Loosen the seven (7) Phillips screws from the battery cover and
remove cover.
9-4
9-3
9-2
9-2
9-1

Razor RSF350 Specifications

General

Run Time	Up to 30 minutes of continuous use
Charge Time	12 hours
Recommended Age	13+
Brakes	Hand-operated, rear disc
Battery	24V sealed lead-acid battery system
Max Speed	Up to 15 mph (24 km/h)
Frame	Steel
Tires	pneumatic front and rear tires
