1. Parts of the Trikke
Two 5mm hex (Allen) keys (supplied)
A. Front wheel
B. Front fork
C. Cambering mechanism
D. Clamp
E. Foot platform
F. Headset (steering
bearings)
G. Collar clamp
H. Quick release clamp
I. T-tube
J. Handlebar
K. Brake levers
L. Grips
M. Brake cables
TOOLS REQUIRED FOR ASSEMBLY ONLY
were selected on the basis of their compatibility with the frame, fork and
all other parts. Certain after-market products may or may not be
compatible with your Razor Trikke 5. Consult your retailer or call Razor
prior to modifying or replacing any component with a non-factory
specified product.
