RBI FlexCore CK 2500 User Manual

MODBUS COMMUNICATIONS HeatNet Control V3
Page 119
MODBUS Input/Output Variables (Read/Write)
Address
Name
Raw Data Type
Scale
Description
Valid Values/Range
40010
SetMonth
8 bit unsigned
---
Set real time clock – month (see SetClock)
0 (January) - 11
(December)
40011
SetDay
8 bit unsigned
---
Set real time clock – day (see SetClock)
1 – 31
40012
SetYear
8 bit unsigned
---
Set real time clock – year (see SetClock)
0 – 99
40013
SetHour
8 bit unsigned
---
Set real time clock – hour (see SetClock)
0 – 23
40014
SetMinute
8 bit unsigned
---
Set real time clock – minute (see SetClock)
0 – 59
40015
SetSecond
8 bit unsigned
---
Set real time clock – second (see SetClock)
0 – 59
40016
SetWeekday
8 bit unsigned
---
Set real time clock – weekday (see
SetClock)
1 (Monday) - 7
(Sunday)
40017
SetClock
1 bit unsigned
---
Set (write) the real time clock.
Do Not Write more than once per minute
To write the real time clock, the system
variables (SetMonth, SetDay, SetYear,
SetHour, SetMinute, SetSecond,
SetWeekday) must first be loaded with the
correct date and time. Then, a 1 must be
written to the state portion of this system
variable to write the new date and time to
the system clock.
0 = no action
1 = set/write the clock
40018
DHWSetpoint
16 bit signed
1.0
DHW Setpoint
40 - 200 °F
40019
BMSGPMRate
16 bit unsigned
1.0
GPM rate to be loaded by BMS for
calculating how many boilers can run based
on flow.
0-1500 GPM
40020
BMSLimitBoilers
16 bit unsigned
1.0
Write the # of boilers that the BMS allows
to fire. If x boilers are available, x becomes
less than or equal to LimitBoilers.
0-16
MODBUS Input Variables (Read Only)
Address
Name
Raw Data
Type
Scale
Description
Valid Values/Range
30001
BoilersOn
8 bit unsigned
---
The number of boilers currently
running.
0 – 16
30002
Modulation
8 bit unsigned
0.01
Current system modulation level.
0 – 100 %
30003
HeaderTemp
16 bit signed
0.01
Header / System temperature.
32 – 250 °F
30004
SupplyTemp
16 bit signed
0.01
Supply temperature.
32 – 250 °F
30005
ReturnTemp
16 bit signed
0.01
Return temperature.
32 – 250 °F
30006
OutsideTemp
16 bit signed
0.01
Outside air temperature.
-40 – 250 °F
30007
DHWTemp
16 bit signed
0.01
Domestic Hot Water temperature
32 – 250 °F
30008
StackTemp
16 bit signed
0.01
Stack temperature
0 – 500 °F
30009
Month
8 bit unsigned
---
Real time clock month.
0 (January) - 11
(December)
