RBI FlexCore CK 2500 - Page 47

CONTROL METHODS HeatNet Control V3
Page 47
DHW Method 4b Quick Start Settings
DHW METHOD 4b: Space Heating with DHW Override of Setpoint on Master Using a 10K Tank Sensor
Master
Settings
Master Type
HeatNet Address
DHW Use Sensor
Combustion Air Damper
Combination
Automatic
Yes
Off
Inputs
Local/Remote
OR OVR
Header Sensor
System Return
DHW Sensor
JPS1 Jumper must be cut
Local
Jumper
Yes
Optional
Yes - Tank
to service DHW
Outputs
System Pump On
Local Pump/Valve On
DHW Pump On
When Boiler Enabled
When Boiler Running
DHW Call
Member 2
Settings
HeatNet Address
Combustion Air Damper
2
Off
Inputs
Local/Remote
JPS1 Jumper must be cut to service DHW
Remote
Outputs
Local Pump On
When Boiler Running
Member 3
Settings
HeatNet Address
Combustion Air Damper
3
Off
Inputs
Local/Remote
JPS1 Jumper must be cut to service DHW
Remote
Outputs
Local Pump On
When Boiler Running
