RBI FlexCore CK 3000 User Manual

MODBUS COMMUNICATIONS HeatNet Control V3
Page 126
MODBUS — BoilerStatus1 Flags
Bit
Description
Valid Values/Range
0
Pilot Valve
0 = closed, 1 = open
1
Blower Running
0 = off, 1 = running
2
Ignition Alarm
0 = ok, 1 = alarm
3
Valve Alarm
0 = ok, 1 = alarm
4
High Limit
0 = ok, 1 = tripped
5
Air Prove Switch
0 = open, 1 = closed
6
RESERVED (FACTORY)
7
Software Operator
0 = off, 1 = on
8
Header Sensor not Detected
0 = detected, 1 = not detected
9
Supply Sensor not Detected
0 = detected, 1 = not detected
10
Return Sensor not Detected
0 = detected, 1 = not detected
11
Outside Sensor not Detected
0 = detected, 1 = not detected
12
System Pump
0 = off, 1 = on
13
Combustion Air Damper
Obsolete –Available only on v1.x controls
0 = off, 1 = on
14
Master Boiler
0 = member, 1 = Master
15
Boiler Detected (at this address)
0 = not detected, 1 = detected
MODBUS — BoilerStatus2 Flags
Bit
Description
Valid Values/Range
0
Disabled – boiler is offline
For instance: Minimum off Time, Flow, Local Override, Calibrate etc.
0 = enabled, 1 = disabled
1
Heat Demand
0 = no demand, 1 = demand (1)
2
Alarm
An alarm or warning condition has occurred. An attempt(s) will automatically
be made to recover and resume normal operation.
0 = ok, 1 = alarm
3
Failed
A condition has occurred under which the boiler can no longer run.
0 = ok, 1 = failed
4
Member Error
An “Alarm” or “Failed” condition has occurred on one (or more) of the
member boilers.
0 = ok, 1 = error
5
Boiler Running
Main Valve is open and Modulation Delay time has expired
0 = off, 1 = running
6
Pump Running
0 = off, 1 = running
7
Spare 3 Interlock
0 = open, 1 = closed
8
LWCO Interlock (Low Water Cut Off)
0 = open, 1 = closed
9
VFD Interlock (Variable Frequency Drive)
0 = open, 1 = closed
