DEFAULT SETTINGS & MENU ITEM DESCRIPTIONS HeatNet Control V3
Page 99
CONTROL SETTINGS MENU— PAGE 1
If operating as a member.
# of first boiler to run, determines the fire order in rotation. A 0
disables the Lead Boiler function. Firing Mode determines lead.
This Box displays the boilers auto detected by H-Net. While M is the
Master boiler the numbers are the H-Net address of each boiler from
2–16.
LOCAL SETPT/
SYSTEM SETPOINT
Local setpoint used to maintain temperature of SETPT SOURCE
System Setpoint is used by the Master.
Differential temp around setpoint used to stage boiler(s) OFF/ON
When running as a member, boiler shuts off when supply
temperature reached.
Boiler restarts at lower temp of OP LIM BAND or 10F whichever is
lower
Limits external input % when in (OP LIM - OP LIM BAND)
AUTO = Local/ System/ WWS Setpoint is used
4-20 mA input is mapped to a setpoint.
