RCA 12L500TD User Manual

Chapter 1: Connections & Setup
Chapter 1 7
1. Connect your VCR to the TV/DVD.
A. Connect the audio (white and red) cables to the AUDIO IN L and R jacks on the right side of the TV/
DVD (when you’re facing it) and to the Audio Output jacks on the VCR (sometimes labeled L and R).
Then connect the video cable (yellow) to the VIDEO IN jack on the TV/DVD and to the Video
Output jack on the VCR.
You can also use this connection for another component, such as a camcorder or video game system.
– OR–
B. Connect a coaxial cable to the ANTENNA JACK on the left side of the TV/DVD (when you’re facing
it) and to the RF Output jack on the VCR (sometimes labeled OUT TO TV). Use the supplied “L”-
adapter to make this connection easier. Connect the coaxial cable from your VCR to the “L”-adapter,
then push the “L”-adapter onto the ANTENNA JACK on the TV/DVD.
2. Make sure cable or antenna is connected to your VCR.
Connect the coaxial cable from your cable outlet or antenna to the antenna input on the VCR (sometimes
labeled In From Antenna).

RCA 12L500TD Specifications

Power

dc power input	19 V
ac/dc power options	AC and 12V DC

Display

screen size	12 inches
aspect ratio	4x3
display resolution	SVGA (800 X 600)
response time	25 ms

Audio

audio power	1 Watt/Channel
speakers	2
sound type	Broadcast Stereo

DVD Capabilities

cd format compatibility	CD, CD-R, CD-RW
dvd format compatibility	DVD, DVD+R, DVD+RW, DVD-RW
intelliseek scan speeds	2x, 4x, 8x, 16x, 32x

Weight and Dimensions

packaged weight	12 lbs
product weight	10 lbs
packaging size	19 1/2 x 9 3/4 x 13 1/2 inches
product size with stand	15.5 x 11.5 x 7 inches
product size without stand	15.5 x 9.5 x 3 inches
