RCA 12L500TD User Manual

Table of Contents
Chapter 1: Connections and Setup
Things to Consider Before You Connect ..................... 3
Protect Against Power Surges .............................. 3
Protect Components from Overheating .............. 3
Position Cables Properly to Avoid Audio
Interference.................................................................. 3
Important Stand and Base Safety Information ... 3
Use Indirect Light .................................................. 4
Cables Needed to Connect Components to
Your TV ......................................................................... 4
Connecting Power and Cable or Antenna .................. 5
Connecting a VCR or Other Component ..................... 6
Jacks on the side of the TV/DVD ................................. 8
Right side (when facing the unit) ........................ 8
Left side (when facing the unit) ........................... 9
Front of the TV/DVD..................................................... 9
Top of the TV/DVD...................................................... 10
Put Batteries in the Remote ....................................... 11
How to Use the Remote Control to Complete
the Initial Setup .......................................................... 12
Turn on the TV/DVD ................................................... 12
Using the Menus......................................................... 12
Complete the Initial Setup ......................................... 13
Complete Auto Channel Search ......................... 13
Next Steps ................................................................... 14
What to Expect ........................................................... 14
TV and DVD Modes ............................................. 14
Menu Systems ...................................................... 14
User’s Guide ......................................................... 14
Remote Control Buttons ............................................ 15
Chapter 2: Playing Discs
DVD Basics................................................................... 17
Regional Coding .................................................. 17
Using Different Menus ........................................ 17
Types of Discs Your DVD Will Play ...................... 17
Loading and Playing Discs .................................. 18
Playback Features ....................................................... 19
Fast Motion Playback (Picture Scan) .................. 19
Skipping Tracks or Songs..................................... 19
Skipping Chapters ............................................... 19
Zoom .................................................................... 19
Using a Disc Menu ............................................... 20
Using the Display Banner........................................... 21
Selecting a Chapter ............................................. 21
Changing the Audio Language .......................... 22
Changing the Subtitle Language ....................... 22
Changing the Camera Angle .............................. 22
Using the Repeat Feature ................................... 23
Playing Audio CDs ...................................................... 24
Using the Repeat Feature ................................... 24
Playing mp3 Discs ....................................................... 25
Selecting Folders and Songs ............................... 25
Skipping Songs .................................................... 26
Changing the Play Mode .................................... 26
1
(continued on next page)

RCA 12L500TD Specifications

Power

dc power input	19 V
ac/dc power options	AC and 12V DC

Display

screen size	12 inches
aspect ratio	4x3
display resolution	SVGA (800 X 600)
response time	25 ms

Audio

audio power	1 Watt/Channel
speakers	2
sound type	Broadcast Stereo

DVD Capabilities

cd format compatibility	CD, CD-R, CD-RW
dvd format compatibility	DVD, DVD+R, DVD+RW, DVD-RW
intelliseek scan speeds	2x, 4x, 8x, 16x, 32x

Weight and Dimensions

packaged weight	12 lbs
product weight	10 lbs
packaging size	19 1/2 x 9 3/4 x 13 1/2 inches
product size with stand	15.5 x 11.5 x 7 inches
product size without stand	15.5 x 9.5 x 3 inches
