TV LED32A30RQ/LED32A45RQ is packaged with the base of TV stand separated from the cabinet. To setup the base of TV table
stand, please carry out the installation according to the instructions below.
Step One
Place the TV faced down on a soft cloth or cushion to prevent the LED LCD panel from being damaged.
Note:
1. The LED LCD panel is easy to scratch, so please choose an absolutely flat surface to place the TV, and use soft cloth or
cushion to protect the TV panel. Do not put TV on table directly.
2. Always unplug the AC cord first when installing or removing the stand.
Step Three
Please align the four holes of the bottom and four screwholes of the neck (align the location labels on the back of base and neck),
then insert the bottom to the neck.
Step Four
Then insert PWA4*12 screws (which are totally the same) and tighten them.
Please refer to the picture given below:
RS01PWA412HT
Pedestal Screws Quantity Part #
4pcsPWA4 x 12mm
The bottom view of the TV ( Front cabinet faces down)
Note:
1. Be sure to follow the instructions. Incorrect installation of the stand may result in the TV falling over.
2. Make sure to distinguish between the front and back of the Stand base.
3. Make sure that at least two persons lift and move the TV.
Do not insert your fingers into the stand base slot of the TV when installing the stand base.
!
Step Two
Take the base of stand. You should take notice of direction about base installation,
please refer to the picture given right side:
TV Front cabinet
TV Back cabinet
TV Stand Installation
9
