4
2. Insert the connector of the AC/DC adapter into the 12V DC input
connector on the rear of the IR transmitter (see figure 3 above).
3. Plug the adapter into a 120 Volt wall outlet.
4. Remove the soft earpads from the earcups by gently lifting them
up. They have plastic tabs that hold them in place to the inside of
the earcup. See figure 4 which illustrates the soft earpads
separated from the earcup on the headset. Insert the two
rechargeable batteries (AAA size) into the left and right battery
compartments, ensuring that the polarity is correct (see figure 4).
Replace the earpads by snapping them back in place on the
earcups. The plastic tabs on the soft earpads must be matched
correctly with the slots in the earcups.
5. Note: Before using the IR headphone for the first time, please
ensure that batteries are fully charged (for 16 hours). This will
guarantee a longer operating life for the batteries.
4
1. Connect the audio signal cable located on the back of the
transmitter to the headphone jack of your audio source. This
headphone jack is located on the front panel of most TVs and
stereo receivers. Insert the plug on the audio signal cable into the
headphone jack. Use the plug adapter included in this package if
the jack is the
1
/4” (6.3 mm) size. If you wish to connect
directly to the “AUDIO OUT” jacks that are standard on most
equipment, then you must purchase a seprate adapter with the
phono plugs at your local dealer.
3.5 mm STEREO PLUG
AC
SOCKET
DC
ADAPTER
AUDIO
CABLE
RECHARGE
CABLE
Figure 3
TO AUDIO
SOURCES
6.3 mm STEREO
ADAPTER
INSTALLATION
RIGHT
