7
7
Figure 5
35° 35°
25 FT.
IR TRANSMITTER
OPTIMUM
LISTENING RANGE
HEADPHONES
RANGE OF
TRANSMITTER
WHR120RS_IB 7/3/02 8:49 AM Page 7

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the RCA WHR120RS and is the answer not in the manual?

RCA WHR120RS Specifications

System Specifications IconSystem Specifications
infrared carrier frequency left channel2.3 MHz
infrared carrier frequency right channel2.8 MHz
modulationFM
frequency response40 - 12, 000 Hz
signal-to-noise ratio50 dB
distortion1% THD
channel separation40 dB
Power IconPower
power supply transmitter200mA, 12V DC
power supply headphone2 X AAA rechargeable batteries
