RCF DU100X - Product Specifications

22
ENGLISH
SPECIFICATIONS
Nominal power 10 W (10-5-2.5-1.2-0.6 W)
Impedance:
(100 V input) 1 kΩ (10 W); 2 kΩ (5 W); 4 kΩ (2.5 W); 8 kΩ (1.2 W); 16 kΩ (0.6 W)
(70 V input) 0.5 kΩ (10 W); 1 kΩ (5 W); 2 kΩ (2.5 W); 4 kΩ (1.2 W); 8 kΩ (0.6 W)
(25 V input) 63 Ω (10 W); 125 Ω (5 W); 250 Ω (2,5 W); 0.5 kΩ (1.2 W), 1 kΩ (0.6 W)
Frequency response 100 ÷ 18’000 Hz
Sensitivity 93 dB (1 m – 1 W)
Sound pressure (10 W) 103 dB (1 m)
Input voltage 100 – 70 – 25 V
Coverage angle
1000 Hz: hor. 195°; vert. 165°
2000 Hz: hor. 100°; vert. 140°
Dimensions:
Weight 1.1 kg
Accessories included drilling template
220 mm / 8.66” 87 mm / 3.42”
190 mm / 7.48”
