Page #35 background image
HDL 30-A HDL 38-AS
Frequency Response 50 Hz - 20 kHz 30 Hz - 400 Hz
Max Spl 137 dB 138 dB
Horizontal Coverage Angle 100° -
Vertical Coverage Angle 15° -
Compression Driver 1.4”, 4.0”v.c. -
Woofer 2x10”, 2.5”v.c. 18”neo, 4.0”v.c.
INPUTS
Input Connector XLR, RDNet Ethercon XRL, RDNet Ethercon
Output Connector XLR, RDNet Ethercon XRL, RDNet Ethercon
Input Sensitivity + 4 dBu + 4 dBu
PROCESSOR
Crossover Frequency 680 Hz Variable from 60Hz to 400Hz
Protections thermal, RMS Thermal, RMS
Limiter soft limiter Soft limiter
Controls
Preset, RDNet Bypass Volume, EQ, phase, xover
AMPLIFIER
Total Power 2200 W Peak 2800 W Peak
High Frequencies 600 W Peak -
Low Frequencies 1600 W Peak -
Cooling Forced Forced
Connections Powercon in-out Powercon in-out
PHYSICAL SPECIFICATIONS
Height 293 mm (11.54”) 502 mm (19.8”)
Width 705 mm (27.76”) 700 mm (27.6”)
Depth 502 mm (19.78”) 621 mm (24”)
Weight 25.0 Kg (55.11lbs) 48,7 Kg (107.4 lbs)
Cabinet PP composite Baltic Birch Plywood
Hardware Array fittings Array fittings, pole
Handles 2 side 2 side
SPECIFICATIONS
