TECHNICAL SPECIFICATION
MQ50
Type Of Speaker: Two way Bass reflex
Speaker: woofer 5” - tweeter 0,75” dome
Sensitivity: 89 dB SPL 1W/1m
Frequency response(-10dB): 70 - 20000 Hz
SPL: 110 dB
Power/RMS: 120/60 W Bypass
Constant voltage: 70,7 - 100 V
Impedance: [Bypass] 16 Ohm
Line transformer [100V]: 333 Ω - 30 W, 500 Ω - 20 W,
1 kΩ - 10 W, 2 kΩ - 5 W
[70.7V]: 333 Ω - 15 W, 500 Ω - 10 W,
1 kΩ - 5 W, 2 kΩ - 2.5 W
Crossover frequencies: 4500 Hz
Crossover: 12/12 dB/oct
Angle of coverage: 120° horizontal x 100° vertical
Protezioni: Dynamic on woofer and tweeter
Cabinet: Hi-density polystirene HB grade
Connectors: Euroblock
Dimension (L x H x P): 160 x 240 x 130 mm
Colour: anthracite grey / white / silver
Weight: 3 Kg
