RCS EPSILON ES4 User Manual

36
+4 2
0000h…03FFh
or 0000h…0FFFh
User’s value of fuel level
+6 2 0000h…FFFFh
Technological value of
fuel level
+8 1 00h…FFh CRC8
A2.3.2.1.2 Unsolicited (periodic) data output (command 07h).
In message current data is transferred: User’s value of fuel level (10 or 12 bits), technological
value of fuel level (16 bit), temperature (8 bits).
Message format:
Drift, byte
Size of field, byte
Value Description
0 1 3Eh Prefix
+1 1 00h…FFh
Network address of
sender
+2 1 07h Command code
+3 1 -128…127
Temperature in degrees
of centigrade
+4 2
0000h…03FFh
or 0000h…0FFFh
User’s value of fuel level
+6 2 0000h…FFFFh
Technological value of
fuel level
+8 1 00h…FFh CRC8
Turning on of the periodic data output is performing by command 55h. In case of receiving of
any valid command periodic data output is disabled, for it’s turning on you have to restart FLS
(switch off and switch on of power supply).
P2.3.2.1.3 Reading of technological parameters (command 41h).
The command is designed for reading of technological parameters of FLS: date of production,
serial number, model code, embedded software version, current calibration data, network
address, period of data output, data output mode.
Command format:
Drift, byte
Size of field, byte
Value Description
0 1 31h Prefix
+1 1 00h…FFh
Network address of
acceptor
+2 1 41h Command code
+3 1 00h…FFh CRC8
Answer format:
