EPSILON ES2,ES4
37
Drift, byte
Size of field, byte
Value Description
0 1 3Eh Prefix
+1 1 00h…FFh
Network address of
sender
+2 1 41h Command code
+3 1 00h…FFh
Year of production: 00h
corresponds to 2000
+4 1 00h…0Bh
Month of production:
00h – January, … , 0Bh
- December
+5 1 01h…1Fh
Day of production:
1…31
+6 3 000005h…FFFFFFh
Serial number
(000005…1048575)
+9 1 01h…92h
Model code
(see next table)
+10 1 01h…FFh
Embedded software
version
+11 1 00h…3Fh Rough calibration
+12 1 00h Reserved
+13 2 0000h…FFFFh Exact calibration
+15 1 F1h Reserved
+16 1 00h Reserved
+17 1 00h…FFh Network address
+18 1 00h…FFh
Period of data output -1
s
+19 1 See table 4.2 Data output mode
+20 1 00h…FFh CRC8
FLS model decoding:
Model code (HEX) Model name Range of probe length, mm
01 ES4-0800 0…800
11 ES4X-1208 800…1200
21 ES4X-1412 1200…1400
31 ES4X-1514 1400…1500
41 ES4XL-1914 1400…1900
51 ES4XL-2119 1900…2100
61 ES4XL-2221 2100…2200
71 ES4XXL-2722 2200…2700
81 ES4XXL-2927 2700…2900
91 ES4XXL-3029 2900…3000
02 ES2-0800 0…800
12 ES2X-1208 800…1200
22 ES2X-1412 1200…1400
32 ES2X-1514 1400…1500
