8
© 2006 Directed Electronics
H1 Harness - 6 pin connector
___
___
___
___
___
___
Pin # Color Note
H1/1
Yellow
Selectable positive or negative parking light output
H1/2
Brown/White
Use this wire if the vehicle is equipped with a
factory alarm. Connect to disarm wire listed on your
sheet.
H1/3
Violet
Connect this wire to supplied hood pin switch
H1/4
Orange
Connect this to wire in vehicle that shows 12 volts
when brake is pressed
H1/5
White/Black
Provides a ground during remote start. This wire is
normally connected to a bypass module if your
vehicle needs one.
H1/6
Red/White
This wire will start the vehicle when it sees two
negative pulses. Only used when incorporating into
existing alarm or for testing purposes.
RED/WHITE (-) remote start activation input
WHITE/BLACK (-) 400mA status output
ORANGE (+) brake switch shutdown input
VIOLET (-) hood pin shutdown input
BROWN/WHITE (-) factory disarm output
YELLOW (+/-) parking light output
HH11//11
HH11//22
HH11//33
HH11//44
HH11//55
HH11//66
