Ready Remote 24927 - H3 Harness - 3 Pin Connector; Relay Heavy Gauge Wires

10
© 2006 Directed Electronics
H3 harness - 3 pin connector
___
___
___
relay heavy gauge wires
___
___
___
___
___
___
BLACK (-) ground
YELLOW (+) starter output
PINK (+) 12 volt input
WHITE (+) accessory output
BLUE (+) ignition 1 output
PINK (+) 12 volt input
GREEN (+) Ign2 or Acc2 output
11
22
33
44
55
66
WHITE/RED (-) unlock/(+) lock
EMPTY
YELLOW/RED (-) lock/(+) unlock
HH33//11
HH33//22
HH33//33
