Headlight Control wire
The Yellow/Brown wire provides an output for activating the
vehicle headlight circuit. It is controlled by both the ignition
switch and the transmitter. It is programmable in Feature Menu
1/10 for the type of ignition controlled activation.
Door Trigger wire
The Gray/Black wire will trigger the alarm and is designed to be
connected to the door switch that turns on the dome light when
the door is opened. It is a negative input circuit only. If your
vehicle uses a positive door switch circuit, call for assistance in
making the connection.
important! this is a low current output and that
requires an external relay when connected to cir-
cuits that draw more than 400mA in current.
