Final Assembly
Update 9/22/14: If you are assembling the PNP version, we recommend that you
remove your motor screws and apply a small amount of blue thread locker.
1. Locate assembled main wings and CF spars 2B & 3B
a. Insert CF spar 2B into forward spar on one wing until it stops.
b. Insert CF spar 3B into rearward spar on one wing until it stops.
c. Slide opposite wing onto spars until wings meet as shown.
2. Fully insert male stereo side of tail boom into boom anchors under main wing.
Note correct side and alignment notches in foam.
