The L. P.G. burner is a fl at steel burner. This burner is supplied with a bag of coarse grain vermiculite, spread this
thinly (5 to 10mm ) over the surface of the burner. Follow instructions for Log and Coal placement as with Natu-
ral Gas burner.
L.P.G. Burner
Ensure all protective covering is removed from all stainless steel panels before subjecting to heat.
Connect the small jack plug lead to the receiver board on the fascia panel. Leave the fascia panel placed in front
of the fi re but not fi tted. The mains power supply needs to be connected and turned on. See instructions for
remote control. Press the power on at the remote. The pilot should ignite, it may take several attempts until the
air has been purged out and gas is through. Once the pilot has ignited the burner will light. Check that the fl ame
travels easily across the burner and that coal placement does not a ect ignition. Re - position logs & coals if re-
quired. Ensure that there is no vermiculite touching the pilot, ignition electrode, or fl ame
sense electrode. This will cause ignition failure.
Commissioning of the Burner
Fill the burner tray with the vermiculite supplied ensuring the burner tube is completely covered. Place the large
logs across each other in the centre of the burner and the twigs and coals around them to cover the burner with
open spacings to allow the radiant heat escape. See drawings of log & coal layout Do not place logs or coals close
to the pilot. See Diagram.
Natural Gas burner
Check the burner from the test point. This is located on the burner supply pipework on Natural Gas models and
on the burner injector on L.P.G.models
Gas pressure
See appliance data badge for pressure settings
Adjust the pressure at the gas valve if required. See valve picture. There are two adjustments, High and low set-
ting. These are located at the front of the valve at the head of the blue solenoid.
High adjustment – This is the outer Brass hexagonal nut
Low Adjustment – This is the inner Red adjustment screw
When adjusting the high setting hold the low adjuster in place otherwise both may turn.
Adjustment of the Burner Gas pressure
