Realtree RTK200 - REAR WHEEL ASSEMBLY; Rear Wheel Hardware; Rear Wheel Installation Procedure

3
Hardware:
REAR WHEEL ASSEMBLY
1
2
M20 Washer 2ea. (1)
4
M20 Castle nuts 2ea. (2)
3
Cotter pins 2ea. (3)
M20 Large
Washer
2ea. (4)
1.Lift the Kart with a jack.
Note: Make sure tire tread faces forward
and Air valve stem is on the outside of the
tire when installing.
3.Install Hub Caps (5) by snapping on hub.
4
1
2
3
Failing t o install co tt er pins
could
be hazardous.
Failing
t o install co tt er pins
could cause
the castle nuts
t o fall off resulting in an
accident.
Nev er operat e Go Kar t
without co tt er pins installed .
5
2. Install rear tire assembly in the
following order:
1. Wheel
2. M20 Large washer (4)
3. M20 Washer (1)
4. M20 Castle nut (2)
5. Colter pin (3)
!
W
ARNING
Make sure
the trend
faces
forward
