Realtree RTK200 - FRONT WHEEL ASSEMBLY; Front Wheel Hardware; Front Wheel Installation Procedure

4
FRONT WHEEL ASSEMBLY
1
2
4
Hardware:
M14 Washer 2ea. (1)
M14 Castle nuts 2ea. (2)
3
Cotter pins
2ea. (3)
M14 Large
Washer
2ea. (4)
1. Lift the Kart with a jack.
Make sure
tread faces
forward
3. Install Hub Caps (5) by snapping on hub.
1.
2. Install the front wheel assembly in the
following order.
2.
Wheel
3.
M14 Large washer (1)
4.
M14 Washer (4)
5.
M14 Castle nut (2)
Colter pin (3)
Failing t o install co tt er pins
could be hazardous. Failing
t o install co tt er pins could
cause the castle nuts t o fall
off resulting in an accident.
Nev er operat e Go Kar t
without co tt er pins installed .
1
23
!
W
ARNING
4
5
