SEAT INSTALLATION
Hardware:
M8 x 35 bolts 2 ea. (1)
M8 Nuts 2 ea. (2)
1. To install the seat, attach
the barb, located on the
bottom of the seat, to the
bracket on the Go Kart
before attaching the bolt.
2. Install the seat with M8x35
bolts (1) and M8 Nuts (2)
SAFETY BELT INSTALLATION
1. Install the self belt on the frame with bolt, washer, nut & gasket.
2
1
1
2
Place bottom portion
of the belt through the
seat.
barb
bracket
