Assemble Your Rec Tec Mini Grill
STEP 1 – Unpack and Prepare for Assembly
Remove all items from inside grill body and lay grill body on its back, with chrome bull horn handles
facing up.
STEP 2 – Unfolding the Legs
The grill should be lying on its back to unfold the legs. First unfold the non-wheeled set of legs by 1
depressing the bar away from the notched hinge mechanism and disengaging the lock. Swing the legs to
the right 2. Repeat for the wheeled set of legs. Ensure that the bar has locked into place in the unfolded
position 3 before standing the grill upright.
5 ©2014, Rec Tec Industries, LLC
UPRIGHT AND LOCKED
LEG POSITION
Ensure bar is fully
engaged in locking
notch.
3
PRESS BAR TO
DISENGAGE LOCK
UNFOLD LEGS AND
LOCK INTO PLACE
1
2
