RM-216 C.10 Easy Line Documentation
RDN 10000029 10 13.05.2014
6 Operating modes
6.1 Test mode
In test mode, the most important functions in the control sequence are checked and shown on the text
display. To start test mode, call up parameter no. P14 “Test mode” (see section 5.2 for more information)
and select one of the following test modes:
Test mode 1 (Valve test)
Each connected valve is activated in sequence and shown in the text display.
Test mode 2 (Input test)
The signal statuses of the inputs are displayed on the text display.
Test modes 3-7
For manufacturer purposes only.
Test mode 0 (test mode off)
Test mode is switched off.
6.2 ∆p-Mode (differential pressure controlled cleaning)
There are two options for switching the differential pressure controlled cleaning on the RM-216 C on and
off:
By setting the parameter P19 “DP-Mode” to the value “On” or “Off”
By pressing the ENTER button for around 3 seconds
If differential pressure-controlled cleaning is switched off, the text “DP-Mode Off” is shown on
the display.
6.3 Down time cleaning modes
Down time cleaning is activated differently depending on the mode selected. Down time cleaning modes
1, 2 and 3 (abbreviated below as DTC modes 1, 2 and 3; Down-Time-Cleaning mode) are available:
