5.3 Parameter list
Parameter
.
no.
Text on the display Explanation Factory settings Setting range
P00
Delta-P Min
∆p-MIN
700 Pa
260 ... 4000 Pa
P01
Delta-P Max
∆p-MAX
1300 Pa
280 ... 4400 Pa
P02
Delta-P Alarm
∆p-Alarm
2300 Pa
300 ... 5000 Pa
P03
Pulse Time
Pulse time
60 ms
30 ... 300 ms
P04
Interval Time
Interval time
10 s
4 ... 500 s
P05
DTC.Interv.Time
Down time interval time
6 s
2 ...100 s
P06
Total Valve no.
Total no. of valves
1
0
0 ... 128
P07
DTC Down Time Cy
Down time cleaning cycles
6
0 ... 32
P08
Delta-P DTC Max
Parameter to activate down time
(DTC modes 2 and 3)
1000 Pa
280 ... 4000 Pa
P09
Delta P DTC Min
Parameter to activate down time
(DTC mode 3)
260 Pa
260 ... 2000 Pa
P10
Hours in operati
Operating hours
–
0 ... 250000 h
P11
Text Language
Language for the display text
D
D, GB, F, I, NL,
DK, FIN, PL
P12
DP-Display Range
Unit of displayed ∆p values
Pa
Pa, mbar,
Inch WC, mm
WG
P13
DTC Cleaning Mod
Down time cleaning mode (DTC-
mode)
2
1 ... 3
P14
Test Mode
0 = Test mode off
1 = Valve test
2 = Input test
3-7 = For manufacturer
purposes only
Off (0)
0 ... 7
P15
dP range
∆p range
0 ... 5000 Pa
0 ... 1000 Pa
to
0 … 5000 Pa
2
P16
Servic.Run Hours
Service operating hours
–
–
P17
Ser.Run Hours AL
Service operating hours alarm
0 h
3
0 ... 25000 h
3
P18
Ser.Run Hou.Code
Service operating hours code
0
–
P19
DP-Mode
Differential pressure mode
On
On / Off
P20
Setting Lock
Parameter setting lock
On
On / Off
1
Number of all valves connected to the RM-216 C and to the expansion modules. The parameter is used by the equipment for
internal monitoring purposes and need only be set, if expansion modules are fitted. If the equipment detects that the total number
of valves set is different from the actual number of valves controlled, an alarm message is issued.
2
The ∆p measuring range of the 4-20 mA signal output 52, 53 is configurable from 0 … 1000 Pa to 0 … 5000 Pa in 500 Pa
increments.
3
If the parameter is set to the value 0 h, the alarm is switched off.
The parameters P03, P06, P07, P08, P09, P13 and P18 are protected by a setting lock at the
factory. If the values need to be changed, the parameter P20 “Setting lock" Must be set to the
value “Off”.
The parameters P10, P16 and P17 are only displayed, if the service operating hours code
(parameter P18) has been entered.
